• 108 Gbps switching capacity
• 4 GPON ports, 4 10GE ports and 4 GE (Electric) ports
• High Capacity Uplink / Service Interface 2.5Gbps (down)/1.25Gbps (up)
• Reliable FTTx service with power redundancy system
• Enhanced QoS services
• IGMP support for IPTV
• Fully Managed via Dasan’s INAS Element Manager
• Increased reliability through power redundancy
• Comfortable network management with SNMPv2 / v3 and RMON

     Input Power

• AC type : 100-240VAC, 50/60Hz
• DC type : -48/60VDC

     Service Ports

• 4 GPON(SFP, SC/PC type)

     Uplink Ports

• 4 GE Electric Port [100/1000Base-T (RJ45)]
• 4 1G/10GBase-R (SFP+) ports

     MGMT Ports

• 1 100/1000Base-TX (RJ45)

     Console Port

• 1 Console (RS232)

     Layer 2

• Standard Ethernet bridging
• Port/Subnet/Protocol-based VLAN
• Spanning Tree: STP, RSTP, MSTP
• 802.3ad Link aggregation based on MAC

     Layer 3

• L3 Host(IPv4/IPv6) 1.5K/768
• Static routing
• 1K L2 Multicast
• 1p mapper service profile on U/S
• Mapping of GEM Ports into a T-CONT with priority queues based scheduling
• Support for Multicast GEM Port

     Multicast

• IGMPv1/v2/v3
• IGMP snooping
• IGMP filtering and throttling
• Multicast VLAN Registration (MVR)

     GPON

•  ITU-T G.984 compliant
• Supports ITU-T G.984.4 ONT Management & Control Interface (OMCI)
• Remote ONT/ONU management
• Automatic ONT ranging
• 4k port-ID and 1k alloc-ID
